7kW Inverter Cool Only
7 Years Extended Warranty
7kW Inverter Cool Only
Model No.
TWS-TSO70C3DVGA
  • Gold Fin Protection
  • Exceptionally Energy Efficient
  • Built-in Wi-Fi
  • Clean Indoor Self Cleaning
  • 3D Air Flow
  • ECO Mode
  • Louvre Memory
  • Timer Mode
  • Scan to Install
  • Interactive Digital Display
  • 4 Way Auto Swing
  • R32 Refrigerant
  • Service Friendly
  • Silent Mode
  • D.R.E.D. Connection
  • Turbo Fan Mode
  • Auto Restart
  • App Control
  • Long Distance Air Flow
  • Refrigerant Leak Detection
  • High Density Filter
  • Active Air PM2.5 Filters
  • Sleep Mode

The TECO 7kW Inverter Cool Only Split System Air Conditioner is your ultimate solution for efficient, eco-friendly cooling. With a high-efficiency inverter compressor and advanced DC inverter technology, it delivers powerful cooling performance while maintaining a consistent temperature for maximum comfort. Its intelligent air distribution system and Eco Mode functionality further enhance energy efficiency, making this air conditioner an ideal choice for those seeking smart features and optimal energy consumption.

  • Gold Fin Protection: Reduces corrosion on outdoor coils, maintaining heat exchange capacity and enhancing the self-cleaning function.
  • Exceptionally Energy Efficient: Achieve up to a 4 -star energy rating, minimizing running costs.
  • Built-in Wi-Fi: Allows control from anywhere via your mobile device. Compatible with Google Assistant and Alexa.
  • Clean Indoor Self Cleaning: Automatic rapid cooling and defrosting to clean the indoor coil and maintain efficiency.
  • 3D Air Flow: Combines vertical and horizontal auto swing for an even distribution of cool air.
  • ECO Mode: Reduces fan speed and adjusts outdoor frequency to minimize energy consumption.
  • Louvre Memory: Recalls the last angle setting of the louvres, eliminating the need to adjust each time you switch on the unit.
  • Timer Mode: Easily set your unit to switch on or off at desired times. Perfect for pre-cooling your home before arrival or automatically turning off after bedtime.
  • Scan to Install: Simplifies the installation process through an easy-to-follow guide via QR code.
  • Interactive Digital Display: Provides easy-to-read information on function status and set temperature.
  • 4 Way Auto Swing: Ensures efficient and uniform cooling throughout the room.
  • R32 Refrigerant: Enhances performance and reduces environmental impact by minimizing Global Warming Potential (GWP).
  • Service Friendly: In-built diagnostics and easily accessible panels make maintenance straightforward.
  • Silent Mode: Activates a quiet function, lowering indoor fan speed and reducing outdoor compressor frequency for a noise-free environment.
  • D.R.E.D. Connection: Equipped with Demand Response Enabling Device Connection (RJ45) to participate in electricity providers’ energy-saving programs (available in Queensland).
  • Turbo Fan Mode: Maximises cooling capacity to quickly reach the desired temperature.
  • Auto Restart: Restores previous settings after a power outage.
  • App Control: Download our AC Freedom app and control your air conditioner remotely with your smart device.
  • Long Distance Air Flow: Powerful fan speeds and 3D air flow ensure comprehensive coverage.
  • Refrigerant Leak Detection: Monitors temperature reduction to catch and prevent refrigerant leaks, protecting the compressor.
  • High Density Filter: Captures more dust and pollen particles with 40% more holes per square centimetre.
  • Active Air PM2.5 Filters: Purifies the air by absorbing dust and airborne particles smaller than 2.5 micrometres, contributing to cleaner, healthier air.
  • Sleep Mode: Gradually adjusts temperature for comfortable sleep and energy savings.

Please Note: Cooling only models only available in QLD, WA & NT.

Model Number Indoor TWS70C3DVGA
Outdoor TSO70C3DVGA
Power supply V – Ph – Hz 220~240 – 1 – 50
Power supply attachment Outdoor
Cooling Capacity (MEPS) kW 7.04 (1.80-7.60)
Running current A 8.5
Power input W 1.950
E.E.R. rating 3.61
Star rating (zone)
(Hot/Med/Cold)
4 / 3.5 / 4
Moisture removal L/Hr 3.0
Indoor fan speeds Turbo/
H/M/L/Silent
5
Indoor cooling air flow (max) L/ 361
Compressor type Rotary
Indoor sound power level dB(A) 64
Outdoor sound power level dB(A) 62
Refrigerant type R32
Connection pipe size
(Liquid / Gas)
mm (inch) 6.35 / 15.9 (1/4″ / 5/8″)
Max. pipe length m 25
Max. height difference m 15
Pipe connection method Flare
Indoor dimensions
(H x W x D)
mm 330 x 1132 x 332
Indoor net weight Kg 14.0
Outdoor dimensions
(H x W x D)
mm 700 x 900 x 350
Outdoor net weight Kg 47.0
Ambient temperature
(Cooling / Heating)
°C 16~52 / -15~32
  • Indoor dimensions (H x W x D) mm 330 x 1132 x 332
  • Indoor net weight Kg 14.0
  • Outdoor dimensions (H x W x D) mm 700 x 900 x 350
  • Outdoor net weight Kg 47.0
Why is the TECO 7kW Inverter unit ideal for large spaces?

The TECO 7kW Inverter unit is designed to deliver powerful cooling across large areas, making it suitable for living rooms, offices, and retail spaces. Its high-efficiency inverter compressor and advanced air distribution system ensure consistent and effective cooling, even in expansive environments.

How does the R32 refrigerant benefit the environment?

R32 refrigerant has a lower Global Warming Potential (GWP) compared to older refrigerants, and it does not deplete the ozone layer. By using R32, the TECO 7kW unit reduces its environmental impact while enhancing cooling efficiency, making it an eco-friendly choice.

What is the benefit of the Timer Mode?

Timer Mode allows you to set specific times for the unit to turn on or off, providing flexibility and convenience. This feature is ideal for pre-cooling your home before you arrive or ensuring that the unit shuts off after you’ve gone to bed, optimizing energy use according to your schedule.

How does the TECO unit ensure quiet operation?

The Silent Mode in the TECO 7kW unit reduces fan and compressor noise, making it ideal for quiet environments such as bedrooms or study areas. This mode ensures that you can enjoy a comfortable temperature without any disturbing noise.

What is the role of Refrigerant Leak Detection in the TECO 7kW unit?

Refrigerant Leak Detection monitors the system for any leaks in the refrigerant line. This feature helps protect the compressor from damage and ensures that the unit operates efficiently, maintaining optimal performance and prolonging the life of the air conditioner.

View more FAQs

Features

  • Gold Fin Protection: Reduces corrosion on outdoor coils, maintaining heat exchange capacity and enhancing the self-cleaning function.
  • Exceptionally Energy Efficient: Achieve up to a 4 -star energy rating, minimizing running costs.
  • Built-in Wi-Fi: Allows control from anywhere via your mobile device. Compatible with Google Assistant and Alexa.
  • Clean Indoor Self Cleaning: Automatic rapid cooling and defrosting to clean the indoor coil and maintain efficiency.
  • 3D Air Flow: Combines vertical and horizontal auto swing for an even distribution of cool air.
  • ECO Mode: Reduces fan speed and adjusts outdoor frequency to minimize energy consumption.
  • Louvre Memory: Recalls the last angle setting of the louvres, eliminating the need to adjust each time you switch on the unit.
  • Timer Mode: Easily set your unit to switch on or off at desired times. Perfect for pre-cooling your home before arrival or automatically turning off after bedtime.
  • Scan to Install: Simplifies the installation process through an easy-to-follow guide via QR code.
  • Interactive Digital Display: Provides easy-to-read information on function status and set temperature.
  • 4 Way Auto Swing: Ensures efficient and uniform cooling throughout the room.
  • R32 Refrigerant: Enhances performance and reduces environmental impact by minimizing Global Warming Potential (GWP).
  • Service Friendly: In-built diagnostics and easily accessible panels make maintenance straightforward.
  • Silent Mode: Activates a quiet function, lowering indoor fan speed and reducing outdoor compressor frequency for a noise-free environment.
  • D.R.E.D. Connection: Equipped with Demand Response Enabling Device Connection (RJ45) to participate in electricity providers’ energy-saving programs (available in Queensland).
  • Turbo Fan Mode: Maximises cooling capacity to quickly reach the desired temperature.
  • Auto Restart: Restores previous settings after a power outage.
  • App Control: Download our AC Freedom app and control your air conditioner remotely with your smart device.
  • Long Distance Air Flow: Powerful fan speeds and 3D air flow ensure comprehensive coverage.
  • Refrigerant Leak Detection: Monitors temperature reduction to catch and prevent refrigerant leaks, protecting the compressor.
  • High Density Filter: Captures more dust and pollen particles with 40% more holes per square centimetre.
  • Active Air PM2.5 Filters: Purifies the air by absorbing dust and airborne particles smaller than 2.5 micrometres, contributing to cleaner, healthier air.
  • Sleep Mode: Gradually adjusts temperature for comfortable sleep and energy savings.

Specifications

Please Note: Cooling only models only available in QLD, WA & NT.

Model Number Indoor TWS70C3DVGA
Outdoor TSO70C3DVGA
Power supply V – Ph – Hz 220~240 – 1 – 50
Power supply attachment Outdoor
Cooling Capacity (MEPS) kW 7.04 (1.80-7.60)
Running current A 8.5
Power input W 1.950
E.E.R. rating 3.61
Star rating (zone)
(Hot/Med/Cold)
4 / 3.5 / 4
Moisture removal L/Hr 3.0
Indoor fan speeds Turbo/
H/M/L/Silent
5
Indoor cooling air flow (max) L/ 361
Compressor type Rotary
Indoor sound power level dB(A) 64
Outdoor sound power level dB(A) 62
Refrigerant type R32
Connection pipe size
(Liquid / Gas)
mm (inch) 6.35 / 15.9 (1/4″ / 5/8″)
Max. pipe length m 25
Max. height difference m 15
Pipe connection method Flare
Indoor dimensions
(H x W x D)
mm 330 x 1132 x 332
Indoor net weight Kg 14.0
Outdoor dimensions
(H x W x D)
mm 700 x 900 x 350
Outdoor net weight Kg 47.0
Ambient temperature
(Cooling / Heating)
°C 16~52 / -15~32

Dimensions

  • Indoor dimensions (H x W x D) mm 330 x 1132 x 332
  • Indoor net weight Kg 14.0
  • Outdoor dimensions (H x W x D) mm 700 x 900 x 350
  • Outdoor net weight Kg 47.0

FAQ

Why is the TECO 7kW Inverter unit ideal for large spaces?

The TECO 7kW Inverter unit is designed to deliver powerful cooling across large areas, making it suitable for living rooms, offices, and retail spaces. Its high-efficiency inverter compressor and advanced air distribution system ensure consistent and effective cooling, even in expansive environments.

How does the R32 refrigerant benefit the environment?

R32 refrigerant has a lower Global Warming Potential (GWP) compared to older refrigerants, and it does not deplete the ozone layer. By using R32, the TECO 7kW unit reduces its environmental impact while enhancing cooling efficiency, making it an eco-friendly choice.

What is the benefit of the Timer Mode?

Timer Mode allows you to set specific times for the unit to turn on or off, providing flexibility and convenience. This feature is ideal for pre-cooling your home before you arrive or ensuring that the unit shuts off after you’ve gone to bed, optimizing energy use according to your schedule.

How does the TECO unit ensure quiet operation?

The Silent Mode in the TECO 7kW unit reduces fan and compressor noise, making it ideal for quiet environments such as bedrooms or study areas. This mode ensures that you can enjoy a comfortable temperature without any disturbing noise.

What is the role of Refrigerant Leak Detection in the TECO 7kW unit?

Refrigerant Leak Detection monitors the system for any leaks in the refrigerant line. This feature helps protect the compressor from damage and ensures that the unit operates efficiently, maintaining optimal performance and prolonging the life of the air conditioner.

View more FAQs
7kW Inverter Cool Only
GOLD Fin Protection

The GOLD Fin Protection on TECO air conditioners is designed to enhance durability by protecting the outdoor coils from corrosion. This added layer of protection helps maintain the unit’s efficiency, ensuring it continues to perform optimally even in harsh environments. It also works in tandem with the Self Clean function, keeping the evaporator coils cleaner for longer, which improves overall air quality and system performance.

Built-In Wi-Fi

With Built-In Wi-Fi, you can easily control your TECO air conditioner from anywhere using your smartphone or tablet. Whether you’re at home or out and about, the intuitive mobile app lets you adjust the temperature, change settings, and even schedule operations remotely. It’s also compatible with popular smart home systems like Google Home and Amazon Alexa, so you can manage your indoor climate with simple voice commands.

7kW Inverter Cool Only
7kW Inverter Cool Only
7kW Inverter Cool Only
7kW Inverter Cool Only
MEPS (Minimum Energy Performance Standards)

TECO air conditioners meet Australia’s Minimum Energy Performance Standards (MEPS), ensuring they deliver excellent energy efficiency and performance. These standards, regulated under the Greenhouse and Energy Minimum Standards Act, guarantee that TECO air conditioners operate effectively across Australia’s varied climate zones, helping you save on energy bills while keeping your home comfortable year-round.

7kW Inverter Cool Only
Interactive Digital Display

Information is displayed on the front panel.

7kW Inverter Cool Only
3D Air Flow

Combines vertical and horizontal auto swing to ensure even distribution of air.

7kW Inverter Cool Only
Timer Mode

Have your unit switch on or off after a period of time you set. Great for switching unit on automatically before you get home or switch off automatically after you go to bed.

7kW Inverter Cool Only
7kW Inverter Cool Only
Scan to install

Download the app for your device

  • Regularly Clean Filters: Keep the filters clean for optimum performance.
  • Use Self-Cleaning Function: Utilize the self-cleaning feature to maintain hygiene.
  • Schedule Professional Maintenance: Annual check-ups ensure smooth operation.
  • Monitor for Refrigerant Leaks: Use the built-in detection function to protect the system.



Talk to us now at hadsales.central@teco.com.au or Find the Retailer near you and take control of your climate with the best in cooling and heating technology

  • Residential Homes: Perfect for living rooms, bedrooms, and home offices.
  • Small to Medium-sized Offices: Ensures a comfortable working environment.
  • Retail Spaces: Keeps customers cool and comfortable.

Maintenance Tips

  • Regularly Clean Filters: Keep the filters clean for optimum performance.
  • Use Self-Cleaning Function: Utilize the self-cleaning feature to maintain hygiene.
  • Schedule Professional Maintenance: Annual check-ups ensure smooth operation.
  • Monitor for Refrigerant Leaks: Use the built-in detection function to protect the system.



Talk to us now at hadsales.central@teco.com.au or Find the Retailer near you and take control of your climate with the best in cooling and heating technology

Ideal Use Cases

  • Residential Homes: Perfect for living rooms, bedrooms, and home offices.
  • Small to Medium-sized Offices: Ensures a comfortable working environment.
  • Retail Spaces: Keeps customers cool and comfortable.
