5kW Inverter Cool Only Split System Air Conditioner Platinum 3D Series
7 Years Extended Warranty
5kW Inverter Cool Only Split System Air Conditioner Platinum 3D Series
Model No.
TWS-TSO50C3DVGA
  • Gold Fin Protection:
  • Exceptionally Energy Efficient
  • Built-in Wi-Fi
  • Clean Indoor Self Cleaning
  • 3D Air Flow
  • ECO Mode
  • Louvre Memory
  • Timer Mode
  • Scan to Install
  • Interactive Digital Display
  • 4 Way Auto Swing
  • R32 Refrigerant
  • Service Friendly
  • Silent Mode
  • D.R.E.D. Connection
  • Turbo Fan Mode
  • Auto Restart
  • App Control
  • Long Distance Air Flow
  • Refrigerant Leak Detection
  • High Density Filter
  • Active Air PM2.5 Filters
  • Sleep Mode
  • Versatility
The TECO 5kW Inverter Cool Only Split System Air Conditioner is equipped with a high-efficiency DC inverter compressor, delivering powerful heating and cooling while ensuring optimal energy consumption. With advanced DC inverter technology, it maintains a consistent temperature for ultimate comfort. Its intelligent air distribution system and Eco Mode functionality enhance energy efficiency, making it the perfect solution for year-round climate control.
  • Gold Fin Protection: Reduces corrosion on outdoor coils, maintaining heat exchange capacity and enhancing the self-cleaning function.
  • Exceptionally Energy Efficient: Achieve up to an 4.5 -star energy rating, minimizing running costs.
  • Built-in Wi-Fi: Allows control from anywhere via your mobile device. Compatible with Google Assistant and Alexa.
  • Clean Indoor Self Cleaning: Automatic rapid cooling and defrosting to clean the indoor coil and maintain efficiency.
  • 3D Air Flow: Combines vertical and horizontal auto swing for an even distribution of cool air.
  • ECO Mode: Reduces fan speed and adjusts outdoor frequency to minimize energy consumption.
  • Louvre Memory: Recalls the last angle setting of the louvres, eliminating the need to adjust each time you switch on the unit.
  • Timer Mode: Easily set your unit to switch on or off at desired times. Perfect for pre-cooling your home before arrival or automatically turning off after bedtime.
  • Scan to Install: Simplifies the installation process through an easy-to-follow guide via QR code.
  • Interactive Digital Display: Provides easy-to-read information on function status and set temperature.
  • 4 Way Auto Swing: Ensures efficient and uniform cooling throughout the room.
  • R32 Refrigerant: Enhances performance and reduces environmental impact by minimizing Global Warming Potential (GWP).
  • Service Friendly: In-built diagnostics and easily accessible panels make maintenance straightforward.
  • Silent Mode: Activates a quiet function, lowering indoor fan speed and reducing outdoor compressor frequency for a noise-free environment.
  • D.R.E.D. Connection: Equipped with Demand Response Enabling Device Connection (RJ45) to participate in electricity providers’ energy-saving programs (available in Queensland).
  • Turbo Fan Mode: Maximises cooling capacity to quickly reach the desired temperature.
  • Auto Restart: Restores previous settings after a power outage.
  • App Control: Download our AC Freedom app and control your air conditioner remotely with your smart device.
  • Long Distance Air Flow: Powerful fan speeds and 3D air flow ensure comprehensive coverage.
  • Refrigerant Leak Detection: Monitors temperature reduction to catch and prevent refrigerant leaks, protecting the compressor.
  • High Density Filter: Captures more dust and pollen particles with 40% more holes per square centimetre.
  • Active Air PM2.5 Filters: Purifies the air by absorbing dust and airborne particles smaller than 2.5 micrometres, contributing to cleaner, healthier air.
  • Sleep Mode: Gradually adjusts temperature for comfortable sleep and energy savings.
  • Versatility: Suitable for various room sizes and applications
ECO Model No. (indoor/outdoor) TWS50H3DVGA TSO50H3DVGA
Power supply V – Ph-Hz 220~240 – 1-50
Power supply attachment Outdoor
Cooling Capacity (MEPS) kW 5.20
(1.30-5.70)
Running current A 5.6
Power input W 1,280
E.E.R. rating 4.06
Star rating (zone) (Hot/Med/Cold) 4.5 / 4 / 4.5
Heating Capacity (MEPS) kW 5.20
(1.30-6.30)
Running current A 5.5
Power input W 1,260
C.O.P. rating 4.13
Star rating (zone) (Hot/Med/Cold) 3 / 2.5 / 2
Moisture removal L/Hr 1.6
Indoor fan speeds Turbo/ H/M/L/Silent 5
Indoor cooling air flow (max) L/s 291
Compressor type Rotary
Indoor sound power level dB(A) 61
Outdoor sound power level dB(A) 60
Refrigerant type R32
Connection pipe size (Liquid / Gas) mm (inch) 6.35 / 12.7 (1/4” / 1/2”)
Max. pipe length m 20
Max. height difference m 10
Pipe connection method Flare
Indoor dimensions
(H x W x D)
mm 315 x 986 x 225
Indoor net weight Kg 13.0
Outdoor dimensions
(H x W x D)
mm 700 x 952 x 380
Outdoor net weight Kg 45.0
Ambient temperature (Cooling / Heating) °C 16~52 / -15~32

Features

  • Gold Fin Protection: Reduces corrosion on outdoor coils, maintaining heat exchange capacity and enhancing the self-cleaning function.
  • Exceptionally Energy Efficient: Achieve up to an 4.5 -star energy rating, minimizing running costs.
  • Built-in Wi-Fi: Allows control from anywhere via your mobile device. Compatible with Google Assistant and Alexa.
  • Clean Indoor Self Cleaning: Automatic rapid cooling and defrosting to clean the indoor coil and maintain efficiency.
  • 3D Air Flow: Combines vertical and horizontal auto swing for an even distribution of cool air.
  • ECO Mode: Reduces fan speed and adjusts outdoor frequency to minimize energy consumption.
  • Louvre Memory: Recalls the last angle setting of the louvres, eliminating the need to adjust each time you switch on the unit.
  • Timer Mode: Easily set your unit to switch on or off at desired times. Perfect for pre-cooling your home before arrival or automatically turning off after bedtime.
  • Scan to Install: Simplifies the installation process through an easy-to-follow guide via QR code.
  • Interactive Digital Display: Provides easy-to-read information on function status and set temperature.
  • 4 Way Auto Swing: Ensures efficient and uniform cooling throughout the room.
  • R32 Refrigerant: Enhances performance and reduces environmental impact by minimizing Global Warming Potential (GWP).
  • Service Friendly: In-built diagnostics and easily accessible panels make maintenance straightforward.
  • Silent Mode: Activates a quiet function, lowering indoor fan speed and reducing outdoor compressor frequency for a noise-free environment.
  • D.R.E.D. Connection: Equipped with Demand Response Enabling Device Connection (RJ45) to participate in electricity providers’ energy-saving programs (available in Queensland).
  • Turbo Fan Mode: Maximises cooling capacity to quickly reach the desired temperature.
  • Auto Restart: Restores previous settings after a power outage.
  • App Control: Download our AC Freedom app and control your air conditioner remotely with your smart device.
  • Long Distance Air Flow: Powerful fan speeds and 3D air flow ensure comprehensive coverage.
  • Refrigerant Leak Detection: Monitors temperature reduction to catch and prevent refrigerant leaks, protecting the compressor.
  • High Density Filter: Captures more dust and pollen particles with 40% more holes per square centimetre.
  • Active Air PM2.5 Filters: Purifies the air by absorbing dust and airborne particles smaller than 2.5 micrometres, contributing to cleaner, healthier air.
  • Sleep Mode: Gradually adjusts temperature for comfortable sleep and energy savings.
  • Versatility: Suitable for various room sizes and applications

Specifications

ECO Model No. (indoor/outdoor) TWS50H3DVGA TSO50H3DVGA
Power supply V – Ph-Hz 220~240 – 1-50
Power supply attachment Outdoor
Cooling Capacity (MEPS) kW 5.20
(1.30-5.70)
Running current A 5.6
Power input W 1,280
E.E.R. rating 4.06
Star rating (zone) (Hot/Med/Cold) 4.5 / 4 / 4.5
Heating Capacity (MEPS) kW 5.20
(1.30-6.30)
Running current A 5.5
Power input W 1,260
C.O.P. rating 4.13
Star rating (zone) (Hot/Med/Cold) 3 / 2.5 / 2
Moisture removal L/Hr 1.6
Indoor fan speeds Turbo/ H/M/L/Silent 5
Indoor cooling air flow (max) L/s 291
Compressor type Rotary
Indoor sound power level dB(A) 61
Outdoor sound power level dB(A) 60
Refrigerant type R32
Connection pipe size (Liquid / Gas) mm (inch) 6.35 / 12.7 (1/4” / 1/2”)
Max. pipe length m 20
Max. height difference m 10
Pipe connection method Flare
Indoor dimensions
(H x W x D)
mm 315 x 986 x 225
Indoor net weight Kg 13.0
Outdoor dimensions
(H x W x D)
mm 700 x 952 x 380
Outdoor net weight Kg 45.0
Ambient temperature (Cooling / Heating) °C 16~52 / -15~32
5kW Inverter Cool Only Split System Air Conditioner Platinum 3D Series
Interactive Digital Display

Information is displayed on the front panel.

5kW Inverter Cool Only Split System Air Conditioner Platinum 3D Series
3D Air Flow

Combines vertical and horizontal auto swing to ensure even distribution of air.

5kW Inverter Cool Only Split System Air Conditioner Platinum 3D Series
Timer Mode

Have your unit switch on or off after a period of time you set. Great for switching unit on automatically before you get home or switch off automatically after you go to bed.

5kW Inverter Cool Only Split System Air Conditioner Platinum 3D Series
5kW Inverter Cool Only Split System Air Conditioner Platinum 3D Series
Scan to install

Download the app for your device

  • Regularly Clean Filters: Keep the filters clean for optimum performance.
  • Use Self-Cleaning Function: Take advantage of the self-cleaning feature to maintain efficiency.
  • Schedule Professional Maintenance: An annual check ensures everything runs smoothly.
  • Monitor for Refrigerant Leaks: Utilise the built-in detection function to safeguard against inefficiency.
  • Residential Homes: Perfect for living rooms, bedrooms, and home offices.
  • Small to Medium-sized Offices: Ensures a comfortable working environment.
  • Retail Spaces: Keeps customers cool and comfortable.
What are the benefits of the ECO Mode on the Inverter Air Conditioner?

The ECO Mode on the TECO 5kW Inverter Air Conditioner reduces fan speed and adjusts the outdoor unit’s frequency to minimize energy consumption. This mode is ideal for energy-conscious users who want to maintain a comfortable temperature while keeping electricity costs low.

How does the Silent Mode improve the comfort of using the unit?

Silent Mode lowers the indoor fan speed and reduces the outdoor compressor frequency, resulting in quieter operation. This feature is perfect for bedrooms, study areas, or any space where minimal noise is essential for comfort and focus.

How does the air conditioner unit handle power outages?

The TECO 5kW unit is equipped with an Auto Restart function that memorizes your last settings and automatically restores them after a power outage. This ensures that your preferred temperature and settings are maintained without the need for manual reconfiguration.

What is the advantage of the Scan to Install feature?

The Scan to Install feature simplifies the installation process by providing easy-to-follow instructions via a QR code. This makes setting up your TECO 5kW unit quick and hassle-free, ensuring that it is installed correctly for optimal performance.

How does the air conditioner contribute to a healthier indoor environment?

The TECO 5kW unit includes a High Density Filter and Active Air PM2.5 Filters that capture dust, pollen, and other airborne particles. The Clean Indoor Self-Cleaning function also helps maintain the cleanliness of the indoor coil, ensuring that the air you breathe is clean and healthy.

View more FAQs

Maintenance Tips

  • Regularly Clean Filters: Keep the filters clean for optimum performance.
  • Use Self-Cleaning Function: Take advantage of the self-cleaning feature to maintain efficiency.
  • Schedule Professional Maintenance: An annual check ensures everything runs smoothly.
  • Monitor for Refrigerant Leaks: Utilise the built-in detection function to safeguard against inefficiency.

Ideal Use Cases

  • Residential Homes: Perfect for living rooms, bedrooms, and home offices.
  • Small to Medium-sized Offices: Ensures a comfortable working environment.
  • Retail Spaces: Keeps customers cool and comfortable.

FAQs

What are the benefits of the ECO Mode on the Inverter Air Conditioner?

The ECO Mode on the TECO 5kW Inverter Air Conditioner reduces fan speed and adjusts the outdoor unit’s frequency to minimize energy consumption. This mode is ideal for energy-conscious users who want to maintain a comfortable temperature while keeping electricity costs low.

How does the Silent Mode improve the comfort of using the unit?

Silent Mode lowers the indoor fan speed and reduces the outdoor compressor frequency, resulting in quieter operation. This feature is perfect for bedrooms, study areas, or any space where minimal noise is essential for comfort and focus.

How does the air conditioner unit handle power outages?

The TECO 5kW unit is equipped with an Auto Restart function that memorizes your last settings and automatically restores them after a power outage. This ensures that your preferred temperature and settings are maintained without the need for manual reconfiguration.

What is the advantage of the Scan to Install feature?

The Scan to Install feature simplifies the installation process by providing easy-to-follow instructions via a QR code. This makes setting up your TECO 5kW unit quick and hassle-free, ensuring that it is installed correctly for optimal performance.

How does the air conditioner contribute to a healthier indoor environment?

The TECO 5kW unit includes a High Density Filter and Active Air PM2.5 Filters that capture dust, pollen, and other airborne particles. The Clean Indoor Self-Cleaning function also helps maintain the cleanliness of the indoor coil, ensuring that the air you breathe is clean and healthy.

View more FAQs
